Blauberg Iso-RB EC 100

Centrifugal inline fans with backward curved blades in cases with improved sound insulation properties with EC-motors

	Unit of measurement	Iso-RB EC 100
Phases	-	1
Minimum supply voltage	V	230
Maximum supply voltage	V	230
Power supply frequency	Hz	50/60
Maximum airflow	m³/h	341
Weight	kg	12
Transported air temperature (max)	°С	55
Transported air temperature (min)	°С	-25
Ingress protection rating	-	IPX4
Ingress protection rating of the drive	-	IP44
Impeller material	-	Plastic

Trademark	Blauberg
Model	Iso-RB EC 100
Specific energy consumption (SEC) (kWh/(m²/a))	Cold		Average		Warm
	-53.9	A+	-26.8	B	-11.3	E
Type of ventilation unit	Unidirectional
Type of drive installed	Variable speed
Type of heat recovery system	None
Maximum flow rate (m³/h)	310
Electric power input (W)	76
Reference flow rate (m³/s)	0.06
Reference pressure difference (Pa)	50
Specific power input (SPI) (W/(m³/h))	0.112
Control typology	Local demand control
Maximum external leakage rates (%)	2.7
Declared typology	RVU UVU
Sound power level (dB(A))	57
The annual electricity consumption (AEC) (kWh/a)	Cold		Average		Warm
	59		59		59
The annual heating saved (AHS) (kWh/a)	Cold		Average		Warm
	5536		2830		1280
